WebCategoryImage Phantom HSS-E Side and Face Milling Cutter DIN 885-A type H‚ staggered teeth 125x18mm
Drawing Phantom HSS-E Side and Face Milling Cutter DIN 885-A type H‚ staggered teeth 125x18mm
WebCategoryImage
Limited in stock | 1 pieces

Phantom HSS-E Side and Face Milling Cutter DIN 885-A type H‚ staggered teeth 125x18mm

382101218
WebCategoryImage Phantom HSS-E Side and Face Milling Cutter DIN 885-A type H‚ staggered teeth 125x18mm
Drawing Phantom HSS-E Side and Face Milling Cutter DIN 885-A type H‚ staggered teeth 125x18mm
WebCategoryImage
€518.00

DIN 885-A, type N

To machining materialsdownload legend
Very adequate for unalloyed and low-alloyed steel ≤600 N/mm²
25-30D
Very adequate for Unalloyed and low-alloyed steel 600 - 850 N/mm²
20-25C
Very adequate for Alloyed steel 850 - 1000 N/mm²
15-20A
Adequate for Alloyed steel 1000 - 1400 N/mm²
10-15A
Very adequate for Stainless steel, ≤850 N/mm²
10-15B
Very adequate for Stainless steel, >850 N/mm²
8-12A
Very adequate for Grey cast iron GG HB<260
17-22B
Very adequate for Nodular and malleable cast iron HB<260
20-25B
Adequate for Aluminium and Aluminium alloys
95-105B
2530
VC: 27 M/min,
Spindle speed n: 69 RPM
Feed/Tooth: 0.08 mm
Feed f: 121 mm/min
  • 98.5% available from stock
  • Real time stock level check
  • Ordered before 19:00 on working days, shipped today
  • You can reach us till 18:00

Specifications

Diameter Ø (d1)
125 mm
Thickness (b1)
18 mm
Diameter Ø (d3)
47 mm
Bore Ø (d2)
32 mm
Shank type
Bore
Number of flutes (z)
22
Norm
DIN 885-A
Tool material
HSS-E
Surface
Bright
Coolant feed
No
Tolerance d1 (Tol. d1)
js16
Tolerance d2 (Tol. d2)
H7
Tolerance b1 (Tol. b1)
k11
Intrastat (HS) code
82077037
EAN code
8716563380603
